YK300H Recommend cutting parameters table for plasma cutting

Views: 0     Author: Site Editor     Publish Time: 2025-04-07      Origin: Site

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

YK300H3(1)

work-piece thickness Current Nozzle hole diameter Gas pressure Piercing time Positioning height Cutting height Cutting speed Remarks
mm A mm Mpa S mm mm mm/min This data is based on carbon steel, if cut stainless steel, copper and aluminum, please reduce the cutting speed accordingly.  if increase the cutting speed, current should be increased together,nozzle diameter should be changed accordingly
6 60-100 1.6 0.5 0.3 5-8 4-6 2500-3500
8 80-120 1.6 0.5 0.5 5-8 4-6 1500-1800
10 80-120 1.6 0.5 0.5 5-8 4-6 1400-1600
12 120-140 1.6 0.5 0.5 5-8 5-8 1400-1600
14 130-160 1.6 0.55 0.5 5-8 5-8 1400-1600
16 140-160 1.8 0.55 0.8 5-8 5-8 1200-1600
18 160-180 1.8 0.55 1.0 5-8 5-8 1200-1400
20 190-220 2.2 0.55 1.5 8-10 5-8 1200-1400
25 220-250 2.5 0.55 1.5 8-10 5-8 1000-1300
30 250-280 2.5/2.8 0.5 0.8 8-10 5-8 700-1000
35 300 2.8 0.5 2.0 8-10 5-8 600-700


Note: The above paramters are only for reference,please adjust it according to actual working conditions
