How to use a memory card to upgrade the Flash

Views: 1     Author: Site Editor     Publish Time: 2022-12-23      Origin: Site

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

How to use a memory card to upgrade the Flash

如果您已经获得了带有程序的SD卡,可直接跳到最后2.3进行刷机操作)

(If you have already obtained an SD card with program, you can skip directly to the last 2.3 to Flash)

. 刷程序前的准备

I. Preparation before Flash

1.1.内存卡(容量在16G以下,过大将会导致刷程序异常)

1.1. Memory card (capacity below 16Gtoo large will result in abnormal Flash)

系统显示屏一般为SDHC大卡

The system display is generally a large SDHC card

送丝机显示屏一般为小卡

The wire feeder display is generally a small card

1.2.专用读卡器(USB转SD的都可以)

1.2. Dedicated card reader (USB to SD can be)


二. 程序的写入

II. Write to the program

2.1通过读卡器连接到电脑后,右键此设备进行格式化,请注意,在格式化选择中,使用分配单元大小为4096字节

2.1 Once connected to the computer via the card reader, right click on this device to format it, please note that in the format selection, use the allocated unit size of 4096 bytes



2.2把解压后的整个DWIN_SET文件夹(亦可能为其他命名的文件夹)放入内存卡中(相关程序包请向我司询问)

2.2 Place the entire unpacked DWIN_SET folder (or possibly another named folder) onto the memory card (please ask us for the relevant package)



2.3 把带有程序的SD卡在系统断电的状态下插入屏幕的卡槽

2.3 Insert the SD card with the program into the card slot on the screen with the system powered off


2.4 上电等待自动刷包,当第一行尾部出现END,再次断电,拔掉SD卡

2.4 Power on and wait for automatic Flash, when END appears at the end of the first line, power down again and unplug the SD card


2.5 上电刷机完成

2.5 Power on Flash completed
