Handheld 3 in 1 Water Cooling Laser Welding Machine

The Handheld 3-in-1 Water Cooling Laser Welding Machine is an advanced multifunctional system that integrates laser welding, laser cleaning, and laser cutting into one compact and portable unit. Designed for flexibility, precision, and high performance, it is ideal for metal processing, maintenance, and manufacturing industries.
Equipped with an efficient water cooling system, the machine ensures stable operation, extended laser source lifespan, and consistent output even under continuous use.

Laser Power:	1000W 1500W 2000W 3000W
Availability:

Quantity:



Inquire Add to Basket

Model:
MS-HLW
Brand:
HEAVTH

Product Description

Product information

Unbeatable Benefits

●FAST: Up to 4X faster than TIG ●VERSATILE: Wide range of materials – up to 1/4 in. (6.35 mm) ●EASY: Optimized presets reduce learning curve ●CONSISTENT: High-quality, repeatable results ●FLEXIBLE: Simple and challenging applications ●PRODUCTIVE: Pre- and post-weld cleaning capability

Product Details

Model	MS-1000 HLW	MS-1500 HLW	MS-2000 HLW	MS-3000 HLW
Laser Source	1000W	1500W	2000W	3000W
Shielding Gas	Argon,Nitrogen,Air	Argon,Nitrogen,Air	Argon,Nitrogen,Air	Argon,Nitrogen,Air
Input Power	6KW	7KW	9.5KW	12KW
Water Chiller	16L 3000W	16L 3000W	19L 4000w	21L 5000W
Mains Supply	AC220V 1PH	AC220V 1PH	AC380V 3PH	AC380V 3PH
Laser Wavelength	1080±3nm
Fiber Length	10m
Focal Length	150nm
Cooling mode	intelligent water chiller
Overrall Dimension	850450630mm
Total Weight	130kg (155 lbs.)

Material	MS-1000HLW	MS-1500HLW	MS-2000HLW	MS-3000HLW
Stainless Steel	up to 3.5 mm	up to 5 mm	up to 6.5 mm	up to 9 mm
Galvanized Steel	up to 3.5 mm	up to 5 mm	up to 6.5 mm	up to 9 mm
Mild Steel	up to 3mm	up to 4mm	up to 6 mm	up to 9 mm
Aluminum	up to 3 mm	up to 4 mm	up to 5 mm	up to 6 mm

LightWELD - Turnkey Handheld Laser Welding & Cleaning Systems

● Adjustable laser welding power up to 1500 W
●Preset & user-defined modes optimize material-thickness combinations
●Wobble welding controls for 5 mm of additional weld width
● Rear panel provides intuitive connections for power, process gas and external accessory controls
● Cleaning power up to 2500 W peak for greater welding quality and finishing capability

Less Heat & Distortion for More Productivity & Flexibility

TIG welding is a time-consuming, two-handed welding method that requires an experienced, highly-skilled operator. TIG welding may
generate extreme heat that deforms thin materials, produces poor visual finishes, is difficult when welding copper, and limited when welding metals of dissimilar thicknesses.

MIG welding requires consumable wire, material pre-cleaning and beveled joints for thick metals for full penetration. Travel and work angles are limited and vertical positions are extremely challenging.

LightWELD enables dramatically faster welding, is easier to learn and operate, and provides higher-quality, consistent results across a wider range of materials and thicknesses than MIG or TIG with minimal

distortion, deformation, undercut or burn-through.

Factory Presets Ensure Optimized Welds & Cleaning

●Simple preset selection ensures consistent high-quality laser welds and cleaning
●Presets include wobble welding function to accommodate wider seams and for parts with poor fit-up
●Operators can instantly switch between presets to process multiple material-thickness combinations
●Advanced operators can customize presets, save for future use and can be used by novice operators to produce the same results

LightWELD is Fast & Easy to Set Up

●Ergonomic, compact and proven to be the most comfortable and easy to use laser gun with built-in wobble welding functionality.
●2-step trigger and part contact sensor enhance operator safety
●Purpose-built nozzle tips for various weld joint types and pre and post weld cleaning applications
●A single cable from the unit delivers laser power, gas and control connections to the gun

Fast and Easy Setup

●Clearly labeled rear connections make getting started fast and easy
●Simply plug in power cord and gas connection, attach clamp to work surface, and the system is ready to go.
●Laser power, gas, and gun control are delivered through a single cable.
●An ethernet computer connection provides access to advanced parameter settings to fine tune and save process parameters.

Optional Wire Feeding Package

● Wire welding capability extends laser welding applications to poorly fit-up parts
●Used for low carbon steel, stainless steel, aluminum and non-ferrous metals and alloys
●Wire feed speed range 40 – 600 cm/min (15 - 230 ipm)
●Wire diameter capacity 0.8 to 1.6 mm ( 0.035''- 0.063'')
●Wire feed tips: 0.8mm, 0.9mm, 1.2mm, 1.6mm

Handheld Laser Welding & Cleaning Systems

Easy to Learn
Built-in factory presets for welding and cleaning reduce learning curves, new welders can be trained within hour and experienced welders realize an immediate increase to productivity
Highly Productive
High-speed welding that is 4X faster than TIG, with simple material preparation and minimal post-finishing, plus wobble welding and wire feed options for consistent high-quality results
Highly Capable
Easily weld and clean thick, thin and reflective metals with low heat input from < .040" (1.0mm) up to 1/4" (6.35mm) with minimal part distortion, improved visual appearance and increased overall part quality

Cutting finished products show

Product packaging

FAQ

How to operate the machine ?
We will deliver English manual and video with the machine to you. If you still need our help, please contact us.

How can I get the sample to check you quality ?
If you want to welding sample to check the quality, we can help you do this.
Just tell us your needs, when finished the testing, we can send testing video to you, if you need, we also can send welding sample to you.

Does the machine can be customized according to my requirements ?
Yes, we have a strong technical team and have rich experience. Tell us your needs, and we will customize your own solutions
