BR2013A High Quality 6 axis Robot Arm Automatic Industrial Robotic Arm For Welding Cutting Pick up

BR2013A is a six-axis robot developed by BORUNTE for the spraying application industry. It has an ultra-long arm span of 2000mm and a maximum load of 13kg.It has a compact structure, is highly flexible and technologically advanced, it can be applied to a wide range of spraying industryand accessories handling field. The protection grade reaches IP65. Dust-proof and water-proof. The repeat positioning accuracy is ±0.5mm.

Availability:
Quantity:
Inquire Add to Basket

BR2013A is a six-axis robot developed by Heavth for the spraying application industry. It has an ultra-long arm span of 2000mm and a maximum load of 13kg.It has a compact structure, is highly flexible and technologically advanced, it can be applied to a wide range of spraying industryand accessories handling field. The protection grade reaches IP65. Dust-proof and water-proof. The repeat positioning accuracy is ±0.5mm.

Arm Length(mm)：2000

Repeatability(mm)：±0.5

Loading Ability(kg)：13

Power Source(kVA)：6.3

Weight(kg)：385

Item

Range

Max.Speed

Arm

J1

±162.5°

101.4°/s

J2

±124°

105.6°/s

J3

-57°~+237°

 130.49°/s

Wrist

J4

±180°

368.4°/s

J5

±180°

415.38°/s

J6

±360°

545.45°/s

 BR2013A
